Small fid for 3/16 amsteel?

stikine

Treehouser
Joined
Mar 24, 2020
Messages
1,941
Location
Southeast, Alaska
I want to replace the wire rope on my chainsaw winch with equivalent diameter amsteel (3/16) and I will need to put on an eye splice with a thimble on the end. The smallest commercial fids seem to be 1/4 and I assume that would be too large? If that's the case I have seen some made from knitting needles which I could probably find. What diameter and fid length would work for 3/16?


Tree09

Treehouser
Joined
Feb 28, 2017
Messages
9,840
Location
Peoria il
I'm sure there's a right way to do it, but i would likely try a welding rod. Constrictor hitch the end on using some thread then pull it back thru. Might even do a little hook on it with a cutoff wheel if it slips.


Burnham

Woods walker
Joined
Mar 7, 2005
Messages
21,135
Location
Western Oregon
I want to replace the wire rope on my chainsaw winch with equivalent diameter amsteel (3/16) and I will need to put on an eye splice with a thimble on the end. The smallest commercial fids seem to be 1/4 and I assume that would be too large? If that's the case I have seen some made from knitting needles which I could probably find. What diameter and fid length would work for 3/16?
Just a note, Austin...any winch that has run steel cable much will likely show some wear and tear on the edges of the spool and around the fairlead. No problem for the cable...but even tiny rough spots will eat up Amsteel pretty fast.

So go over all those parts with a fine-toothed comb where the cable/rope has running contact, and smooth off any that you can find. You want a very smooth finish.


treesmith

Banned
Joined
Feb 4, 2009
Messages
9,370
Location
Alabama
I made a wire puller fid for splicing hammock whoopies out of 1/8” Amsteel. I used electric fence wire I had laying around and wrapped and tied it off on a small piece of wood to afford pulling grip. I’d think that would work fine for 3/16” too.


flushcut

TreeHouser
Joined
Jan 15, 2011
Messages
18,027
Location
Delavan, WI
How about a wrap or two of electrical tape and walk that through the inside of the braid. Or did you want the fid for measuring?
Never mind on the last bit I reread the original post better.


stikine

Treehouser
Joined
Mar 24, 2020
Messages
1,941
Location
Southeast, Alaska
  • Thread Starter Thread Starter
  • Thread Starter Thread Starter
  • #17
Thanks Jonny, I think I can figure it out. Materials are ordered.
